| 1. Define the gear geometry |
Module, diametral pitch, pressure angle, tooth count, pitch diameter, face width, bore, and keyway |
Common pressure angles: 20° or 14.5°; module often 0.5–6 mm for small and medium gears |
A gear cannot mesh correctly if its tooth geometry is incompatible with the mating gear. |
Provide a dimensioned drawing or a complete CAD model with gear parameters and datum references. |
| 2. Confirm dimensional tolerances |
Outside diameter, bore diameter, face width, hub diameter, tooth thickness, and concentric features |
General CNC dimensions are often about ±0.05 mm to ±0. twintig mm, depending on size, material, and process capability |
Unspecified tolerances can cause loose fits, interference, or inconsistent assembly performance. |
State individual critical tolerances instead of relying only on a general title-block tolerance. |
| 3. Specify radial and axial runout |
Radial runout of the pitch or outside diameter; axial runout of the gear face relative to the bore datum |
A practical starting requirement for precision parts is approximately 0.02–0.08 mm total indicated runout, subject to gear size and application |
Excessive runout can create vibration, uneven tooth loading, noise, and accelerated wear. |
Define the datum axis, inspection location, measurement direction, and maximum TIR value. |
| 4. Set the surface-finish target |
Tooth flanks, bore, hub, side faces, and sealing or locating surfaces |
Typical CNC-milled or turned surfaces may be about Ra 1.6–3.2 µm; finer finishing may achieve Ra 0.8 µm or lower |
Surface texture affects friction, lubrication retention, wear, contact stress, and fit. |
Assign Ra values by surface and identify whether measurement is required before or after finishing. |
| 5. Match material to the load |
Material grade, hardness, tensile strength, operating temperature, lubrication, and corrosion exposure |
Aluminum is lightweight; carbon and alloy steels provide higher strength; engineering plastics can reduce noise and weight |
The wrong material may deform, wear rapidly, corrode, or fail under repeated torque. |
List the exact material specification, required hardness range, and any heat-treatment condition. |
| 6. Clarify inspection and gear accuracy |
Tooth profile, lead, pitch error, tooth thickness, bore size, runout, and surface roughness |
Basic CNC dimensional inspection may use calipers, micrometers, bore gauges, and CMMs; higher gear accuracy requires specialized gear inspection |
A part may meet basic dimensions yet still produce poor meshing because of tooth-form or pitch errors. |
Request an inspection report identifying equipment, measurement uncertainty, datums, and acceptance criteria. |
| 7. Approve a sample before production |
Prototype fit, backlash, tooth contact pattern, noise, rotation smoothness, and assembly clearance |
Backlash depends on module, center distance, accuracy grade, lubrication, temperature, and operating requirements |
Functional testing can reveal meshing or assembly issues that dimensional inspection alone may miss. |
Approve a first article using the actual mating gear, shaft, bearing arrangement, and intended lubricant where possible. |
